    Single Wire Cable Vertical Burning Flame Test Chamber Flammability Machine

    Ask Lasest Price
    Brand Name : GC
    Model Number : GC-DRS-A
    Certification : ISO
    Price : Negotiated
    Payment Terms : TT
    Supply Ability : 100 Sets
    Delivery Time : In stock
    • Product Details
    • Company Profile

    Single Wire Cable Vertical Burning Flame Test Chamber Flammability Machine

    Single Wire and Cable Vertical Burning Testing Machine


    Product description:


    GC-DRS-A single wire and cable vertical burning tester is suitable for measuring the vertical burning non-spreading performance of single plastic wire, control wire, cross-linked, elevator, ship, mining cable, etc. It can also be used for vertical burning test of high self-extinguishing low-smoke halogen-free flame-retardant olefin irradiated insulating material.


    Test Standards


    GB/T 18380.11-2008 Combustion test of cables and fiber optic cables in flame conditions Part XI

    GB/T 18380.12-2008 Combustion test of cables and fiber optic cables in flame conditions Part XII

    IEC60332-1-2:2004 Optical cable burning test

    IEC60332-1-3:2004 Insulated wire dripping test

    IEC60332-2-1:2004 Test of cables and optical cables under fire conditions

    IEC60332-2-2:2004 Cable and optical cable test in fire environment

    En50265-1 VDE low smoke halogen-free flame retardant test standard

    GB/T5169.14-2007 Fire hazard test of electric and electronic products Part 14

    IEC60695-11-2:2003 Fire Hazard Test - Part 12


    Technical Parameter

    Model

    GC-DRS-A

    Burning box

    30*120*45(W*H*D)

    Burning blowtorch

    1KW combustion nozzle, blue flame height is 50 to 60mm, the total height of the flame is 170 to 190mm

    Gas

    Using high-purity 95% technical grade propane gas

    Sample length

    600±25mm

    Sample bracket

    The distance between the lower edge of the upper bracket and the upper edge of the lower bracket of the two horizontal brackets is 550mm

    Fire time

    0.1-999.9s continuous setting

    Control function

    Choose manually or automatically

    Gas flow range

    100-1000ml/min

    Air flow range

    1-10L/min

    Pressure gauge

    0~0.75kpa (adjustable)

    Ignition method

    High-voltage automatic ignition

    Power

    AC220V, 50Hz
