    Mechanical Hot And Cold Thermal Shock Testing Machine For Environmental Test OEM

    Ask Lasest Price
    Certification : ISO
    Brand Name : GC
    Delivery Time : In stock
    Payment Terms : TT
    Supply Ability : 100 Sets
    Price : Negotiated
    Model Number : GC-CJ-100
    • Product Details
    • Company Profile

    Mechanical Hot And Cold Thermal Shock Testing Machine For Environmental Test OEM

    Hot And Cold Thermal Shock Test Machine For Environmental Test

    Product Description

    1.Hot and cold shock test chamber, is a metal, plastic, rubber, electronics and other materials industry necessary test equipment, used to test material structure or composite materials, in an instant under the extreme high temperature and low temperature continuous environment to endure the degree of chemical changes or physical damage caused by thermal expansion and contraction of the sample in the shortest time

    2.The system structure of the thermal shock test chamber is divided into high temperature tank (preheating zone) and low temperature tank (precooling zone).

    Temperature shock is carried out to achieve the purpose of drastic temperature change, and the test product is static.

    3.This test chamber is suitable for assessing the ability of complete machine products, components, parts, materials, etc. to withstand rapid temperature changes.

    The temperature shock test is used to evaluate the chemical changes or physical damage of test samples caused by thermal expansion and contraction in the shortest time.

    4.It is possible to understand the influence of temperature changes on test samples once or several times in succession.

    The main parameters affecting the temperature change test are the high temperature and low temperature values of the temperature change range, the retention time of the test sample at high temperature and low temperature, and the number of cycles of the test and other factors.

    5.The hot and cold shock chamber is a necessary test equipment for electronics, LED, metal, plastic, rubber, paint, paint, electronics and other material industries.

    Product Parameters
    Product NameShock Test Chamber
    Internal size80L:W500*H400*D500mm
    External size80L:W1400*H1850*D1500mm
    Temperature shock rangeHigh temperature +60ºC~ +220ºC Low temperature -10ºC~ 80ºC
    Preheating temperature range60ºC--200ºC
    High temperature tank heating timeRT~+200ºC≤30min (RT:+10~+30ºC)
    Precooling temperature range(-10)ºC~ (-70)ºC
    Low temperature tank cooling timeRT~-70ºC≤50min (RT:+10~+30ºC)
    Temperature fluctuation±1.0ºC
    Temperature uniformity±2.0ºC
    Throttle conversion time≤5S
    Impact recovery time(-60)ºC~(+220)ºC≤5min
    Heating systemFin-type radiating tube-shaped stainless steel electric heater
    1, high temperature tank 9KW
    2, low temperature tank 6KW
    CompressorOriginal imported French "Taikang" brand fully enclosed compressor
    EvaporatorMulti-stage automatic load capacity adjustment of bullying fins
    Expansion valveDanvers imported original components from Denmark

    Packaging & Shipping

    FAQ

    High Cost-Effective Durable Hot and Cold Thermal Shock Test Machine

    Quality Mechanical Hot And Cold Thermal Shock Testing Machine For Environmental Test OEM for sale
