    220V Small Temperature Humidity Test Chamber Control R404A Refrigerant

    Ask Lasest Price
    Brand Name : GC
    Certification : ISO
    Delivery Time : In stock
    Payment Terms : TT
    Supply Ability : 300PCS/Month
    Price : Negotiated
    Model Number : GC-TH-80D
    • Product Details
    • Company Profile

    220V Small Temperature Humidity Test Chamber Control R404A Refrigerant

    Constant Temperature and Humidity Test Chamber

    Model: GC-TH-80

    Product Introduction
    This test chamber provides a simulated environment of high temperature, low temperature, high humidity and low humidity to detect the material and strength of rubber, plastic, electronic products before and after testing. The machine can also simulate the container environment to detect the fading and shrinkage of rubber and plastic under high temperature and high humidity. Test the heat resistance, cold resistance, dry resistance and humidity resistance of various materials. It is suitable for quality control testing of factories in electronics, electrical appliances, batteries, universities, research institutes, inspection and quarantine bureaus, paper products, food, vehicles, auto parts, metals, chemicals, building materials and other industries.

    Test Standards
    GB11158Technical Conditions of High Temperature Test Chamber
    GB10589-89Technical Conditions of Low Temperature Test Chamber
    GB10592-89Technical conditions of high and low temperature test chamber
    GB/T10586-89Technical Conditions of Damp Heat Test Chamber
    GB/T2423.1-2008Low temperature test chamber test method
    GB/T2423.2-2008Test method for high temperature test chamber
    GB/T2423.3-2006Damp heat test chamber test method
    GB/T2423.4-2008Test method for alternating damp heat
    GB/T2423.22-2002Test method for temperature change
    IEC60068-2-1.1990Low temperature test chamber test method
    IEC60068-2-2.1974High temperature test chamber test method
    GJB150.3high temperature test
    GJB150.4low temperature test
    GJB150.9Damp heat test
    Features
    1. High-quality appearance, the body adopts arc shape; the surface is treated with matte stripes, and adopts non-reaction handle, easy to operate, safe and reliable.
    2. Rectangular floating layer glass viewing window, which can observe the test items in the test. The window is equipped with an anti-sweat electric heater device to prevent water vapor from condensing and water droplets, and a high-brightness PL fluorescent lamp to keep the inside of the box illuminated.
    3. The double-layer insulation of the box door is tight and airtight, which can effectively isolate the internal temperature leakage.
    4. With an external water supply system, it is convenient to supplement the water supply of the humidification barrel, and it can be recycled and used automatically.
    5. The compressor circulation system adopts the French "Tecumseh" brand, which can more effectively remove the lubricating oil between the condenser tube and the capillary tube, and the whole series adopts environmentally friendly refrigerants (R23/R404/R507)
    6. The controller adopts self-developed LCD display screen, which can display the measured value, set value and time at the same time.
    7. The controller has multi-segment program editing and temperature, humidity can do fast (OUICK) or slope (SLOP) control.
    8. The built-in moving pulley is easy to move and place and has the potential to set the screw to fix the position.

    Specifications
    ModelGC-TH-80D
    Inner box size W*H*D(cm)40*50*40
    Carton size W*H*D(cm)93*138*95
    Inner box volume80L
    Temperature and humidity control length: -70ºC~150ºC RH: 20%-98%
    (Special temperature and humidity specifications can be customized)
    Function

    Temperature and humidity fluctuation±0.5ºC;±2.5%RH
    Temperature and humidity deviation±0.5ºC-±2ºC;±3%RH(>75%RH); ±5%RH(≤75%RH)
    Controller resolution±0.3ºC;±2.5%RH
    Controller BrandProgrammable U680 touch screen controller
    Material
    Inner wallSUS304#steel plate
    Outer wallSUS304#steel plate mist treatment
    Thermal insulation materialHigh temperature resistant high density ethyl chloroformate foam insulating material
    System air circulation modeCentrifugal fan-broadband forced air circulation
    Cooling modeSingle stage mechanical compression system
    Refrigerating machineFully enclosed piston French TECUMSEH compressor
    RefrigerantR404A or American DuPont environmental refrigerant (R23+R404)
    Condensation methodAir-cooled
    HeaterNi-Cr wire heater
    HumidifierSemi-closed steam humidification
    Water supply modeAutomatic circulating water supply
    Safety deviceNo fuse switch,( compressor overload, refrigerant high and low pressure, ultra-humidity and over-temperature) protection switch, fuse failure warning system)
    Power220V AC±10% 60HZ
