Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus

    Buy cheap Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus from wholesalers

    Buy cheap Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus from wholesalers
    • Buy cheap Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus from wholesalers
    • Buy cheap Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus from wholesalers

    Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus

    Ask Lasest Price
    Brand Name : GC
    Certification : ISO
    Delivery Time : In stock
    Payment Terms : TT
    Supply Ability : 100 Sets
    Price : Negotiated
    Model Number : GC-JZL-A
    • Product Details
    • Company Profile

    Engineering Plastic Rubber Charpy Impact Testing Machine Apparatus

    Selection Imported Digital Charpy Impact Testing Machine For Plastic And Rubber

    Product Description

    -The digitdl Izod impact testing machine is a device used to measure the impact strength or toughness of a material.

    It is commonly used in engineering and manufacturing industries to assess the ability of a material to withstand sudden impacts or shocks.

    The results of Izod impact tests are crucial for ensuring the safety and reliability of products in various applications, such as automotive components, structural elements, and consumer goods.
    -The machine consists of a pendulum with a striking edge, which is released from a certain height to strike a notched sample of the material being tested.

    The pendulum's energy at the point of impact is measured, and this value is used to calculate the material's impact strength.

    Selection Imported Digital Charpy Impact Testing Machine for Plastic and Rubber


    Product Parameters
    Product NameDigital Izod Impact Test Machine
    ItemIZOD
    The pendulum energy11J 12J
    Display modeColor touch screen
    Cutting methodHand automatic integration
    Pendulum pre-evaluation angle150ºC
    Impact velocity3.5m/s
    Angle accuracy0.01J
    Distance between Pendulum and the impact blade335mm
    Distance between impact blade to upper mouth22mm
    Blade fillet radiusR=0.8±0.2mm
    Output methodPrintout
    Power220V,50HZ
    After-sales Service12 months
    HS Code9024800000
    PackageWooden package
    Power SourceAC220V
    Company Profile

    -Guangce main products are: melt flow index tester, pendulum impact testing machine, tensile testing machine,

    thermal deformation Vicat softening point testing machine, constant temperature and humidity test chamber,

    thermal shock test chamber, high and low temperature test chamber, xenon aging test chamber,

    ozone aging test chamber, high and low temperature tensile testing machine, combustion test chamber and other testing machines


    Selection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and Rubber

    Packaging & Shipping

    Selection Imported Digital Charpy Impact Testing Machine for Plastic and RubberSelection Imported Digital Charpy Impact Testing Machine for Plastic and Rubber

    FAQ

    Selection Imported Digital Charpy Impact Testing Machine for Plastic and Rubber
